ELN Series MEAN WELL 30 ~ 60W Constant Current LED Drivers
More images
Regular Price: $30.24
Sale Price: $27.21
You Save: $3.03
PART #: ELN-X-X
VOLUME DISCOUNTS
PCS
% OFF
10 - 49
5%
50 - 99
7.5%
100 - 249
15%
250 - 499
20%
First Class > $39.99
FREE
First Class
$3.99
Ground
$11.99
2-Day
$13.99
Express
CALC
Purchase
ORDER BY 3PM EST FOR
SAME DAY SHIPPING
SAME DAY SHIPPING
- Universal AC Input / Full Range
- Class 2 Power Unit
- Multiple Dimming Options
Share:
Product Details
| INPUT POWER: 90 ~ 264Vac | CASING: Fully isolated plastic case IP64 NON PFC |
| OUTPUT: Constant current limiting circuit with adjustable OCP level | WATTS: 30W & 60W |
| CONNECTIONS: UL Rated 18AWG 2-Conductor Wire | DIMMING: Optional: 1~10VDC (D-Type) or PWM (P-Type) |
| WARRANTY: 2-Years | SAFETY: Class 2 Power Unit, Short-Circuit, Over Current & Over-Voltage |
| Universal AC input / Full range | APPLICATIONS: Indoor LED lighting & LED Electronic Displays |
Description
Mean Well’s ELN series runs off line voltage (90~264VAC) and has a built-in constant current limiting circuit with adjustable OCP levels. The ELN LED driver series comes in 30 and 60 Watt models in which you can change the output voltage and current with internal potentiometers. These drivers come in a fully isolated plastic case that is IP64 rated. The wire connections use UL rated 2-conductor wire with 18AWG. If you have specifications and standards for your project, you should know this is a class 2 power unit. This LED driver will allow you to adjust the output voltage and current ranges to your needs, adding a versatility you can't get with just your standard driver.
Dimming Options
The Mean Well ELN constant current LED driver has two different products that offer different dimming compatibility. The D-Type works with 1-10VDC control signal, whereas the P-Type works with PWM (pulse width modulation) control signals.
Support
LEDSupply is formally trained on all Mean Well products, so if there is any confusion please contact us.
Availability
While we do stock many Mean Well models, there may be less popular versions that we do not stock. However, we are able to very quickly pull from a larger inventory and supply any Mean Well product normally within 7-10 business days.
Technical Documentation
Specifications
| Model | Input | Output | Dimming | Dimensions (mm) |
|||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Range (VAC) |
Eff. (Typ.) |
Voltage (DC) |
LED Oper. Volt. (VDC) |
Rated Current (A) |
Current Range (A) |
Rated Power (W) |
Volt. ADJ. Range (VDC) |
Current ADJ. Range |
|||
| ELN-30-5 | 90~264VAC | 75% | 5VDC | 3 ~ 5VDC | 5A | 0 ~ 5A | 25W | 4.5 ~ 5.5VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 145(L) x 47(W) x 30mm (H) |
| ELN-30-9 | 90~264VAC | 80% | 9VDC | 3 ~ 9VDC | 3.4A | 0 ~ 3.4A | 30.6W | 8.7 ~ 10.5VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 145(L) x 47(W) x 30mm (H) |
| ELN-30-12 | 90~264VAC | 82% | 12VDC | 3 ~ 12VDC | 2.5A | 0 ~ 2.5A | 30W | 10.8 ~ 13.2VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 145(L) x 47(W) x 30mm (H) |
| ELN-30-15 | 90~264VAC | 82% | 15VDC | 3 ~ 15VDC | 2A | 0 ~ 2A | 30W | 13.5 ~ 16.5VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 145(L) x 47(W) x 30mm (H) |
| ELN-30-24 | 90~264VAC | 85% | 24VDC | 3 ~ 24VDC | 1.25A | 0 ~ 1.25A | 30W | 21.6 ~ 26.4VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 145(L) x 47(W) x 30mm (H) |
| ELN-30-27 | 90~264VAC | 85% | 27VDC | 3 ~ 27VDC | 1.12A | 0 ~ 1.12A | 30.24W | 24.3 ~ 29.7VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 145(L) x 47(W) x 30mm (H) |
| ELN-30-48 | 90~264VAC | 87% | 48VDC | 3 ~ 48VDC | 0.63A | 0 ~ 0.63A | 30.24W | 43.2 ~ 52.8VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 145(L) x 47(W) x 30mm (H) |
| ELN-60-9 | 90~264VAC | 82% | 9VDC | 3 ~ 9VDC | 5A | 0 ~ 5A | 45W | 8.7 ~ 10.5VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 181(L) x 61.5(W) x 35mm (H) |
| ELN-60-12 | 90~264VAC | 85% | 12VDC | 6 ~ 12VDC | 5A | 0 ~ 5A | 60W | 10.8 ~ 13.2VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 181(L) x 61.5(W) x 35mm (H) |
| ELN-60-15 | 90~264VAC | 86% | 15VDC | 7.5 ~ 15VDC | 4A | 0 ~ 4A | 60W | 13.5 ~ 16.5VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 181(L) x 61.5(W) x 35mm (H) |
| ELN-60-24 | 90~264VAC | 87% | 24VDC | 12 ~ 24VDC | 2.5A | 0 ~ 2.5A | 60W | 21.6 ~ 26.4VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 181(L) x 61.5(W) x 35mm (H) |
| ELN-60-27 | 90~264VAC | 87% | 27VDC | 13.5 ~ 27VDC | 2.3A | 0 ~ 2.3A | 62.1W | 24.3 ~ 29.7VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 181(L) x 61.5(W) x 35mm (H) |
| ELN-60-48 | 90~264VAC | 88% | 48VDC | 24 ~ 48VDC | 1.3A | 0 ~ 1.3A | 62.5W | 43.2 ~ 52.8VDC | -25% ~ 3% | 1.1~ 10VDC or PWM | 181(L) x 61.5(W) x 35mm (H) |
Misc. Characteristics
Characteristics
ELN Series
VOLTAGE OUTPUT
Can be adjusted by internal potentiometer SVR1
CURRENT OUTPUT
-25% ~ 3%. Can be adjusted by internal potentiometer SVR2
VOLTAGE TOLERANCE
±5.0%
LINE REGULATION
±1.0%
LOAD REGULATION
±2.0%
SETUP, RISE TIME
500ms, 30ms / 230VAC 1500ms, 30ms / 115VAC at full load
HOLD UP TIME
50ms/230VAC 16ms/115VAC at full load
FREQUENCY RANGE
47 ~ 63Hz
LEAKAGE CURRENT
0.25mA / 240VAC
OVER CURRENT
95 ~ 110% : Constant current limiting, recovers automatically after fault condition is removed
OVER VOLTAGE
Protection type: Shut down o/p voltage, re-power on to recover
DIMMING CONTROL
1 ~ 10VDC or PWM Signal : 100Hz ~ 3KHz
WORKING TEMP.
-20 ~ 60°C (Refer to "Derating Curve")
WORKING HUMIDITY
20 ~ 90% RH non-condensing
STORAGE TEMP., HUMIDITY
-40 ~ +80°C, 10 ~ 95% RH
TEMP. COEFFICIENT
±0.03%/°C (0~50°C)
VIBRATION
10~500Hz, 2G 10min./1cycle, period for 60min. each along X,Y,Z axes
SAFETY STANDARDS
UL1310, CAN/CSA C22.2 No. 223-M91 (except for 48V), IP64 approved; design refer to TUV EN60950-1
WITHSTAND VOLTAGE
I/P-O/P:3KVAC
ISOLATION RESISTANCE
I/P-O/P:>100M Ohms / 500VDC / 25°C / 70% RH
EMC EMISSION
Compliance to EN55022 (CISPR22) Class B, EN61000-3-2 Class A, EN61000-3-3
EMC IMMUNITY
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, light industry level, criteria A
